Glass Washing Dryer Series
The Glass Washing Dryer Series is a line of innovative and efficient machines designed to wash and dry glassware quickly and effectively. With advanced technology and customizable settings, this series is ideal for bars, restaurants, and other establishments looking to maintain sparkling clean glassware.
Function
● Steel frame with aluminum profile assembly structure
● Stainless steel for the water contact part, and baking paint for the frame.
● Washing and air-drying section can be lifted up and down as a whole, the maximum stroke:350
● With pre-spraying (two drains, independent water tank).
● The first dual-power transmission, efficient and rapid
● Three sets of brushes + three sets of wind knife configuration structure
● Transmission for helical gear structure, frequency control, digital display cleaning section up and down drive brush for independent transmission, frequency control;
● PLC control, touch screen display is convenient for operation and maintenance.
Product parameters
| Model No | HQX1600 | HQX2000 | HQX2500 |
| Brush&Air Knife Configuration | 3 pairs of Brushes (1*top Low-E brush), 3 pairs of Air Knife (2*Straight & 1*Inclined) | ||
| Min.Glass Size | 350*350mm(Diagonally) | ||
| Glass Thickness | 3-19mm | ||
| Speed | 3-15m/min(Frequency Control) | ||
| Max.Lifting Height | 400mm | ||
| Working Height | 860~960mm | ||
| Max.Glass Width | 1600mm | 2000mm | 2500mm |
| Weight | 3.6t | 4t | 4.5t |
| Power | 24kw | 28.5kW | 32kW |
| Air Supply | 0.6Mpa~0.8Mpa，Ф8 | ||
| Recycling Water | 0.55kw*4 | 4pcs Independent Water Tanks, Pump 0.75kw *4 | 4pcs Independent Water Tanks, Pump 0.75kw *4 |
| Machine Size(LxWxH) | 6080x3300x2600mm | 6240x3700x2600mm | 6400x4200x2600mm |
| Separate Power In Feed Section | (Option)0.75KW Frequency Conversion | (Option)1.1Kw Frequency Conversion | (Option)1.1KW Frequency Conversion |
| Water Heating | (Option)4kW*3 | (Option)5kw*3 | (Option)5kW*3 |
| Fan Frequency Conversion | (Option) | ||
| Air Heating | (Option) | ||
